A2212/13T Brushless Motor 2200 kv BLDC Airplane Outrunner Brushless Motor
Including GST (No Hidden Charges)
Checkout securely with
A2212 BLDC Motor is a 3-phase out-runner type popular BLDC motor commonly used in Drones and other multirotor applications. The motor is rated for 2200KV and has an efficiency of 80%. The A2212 motor requires an ESC (Electronic speed controller) to control its speed. The motor can be easily be controlled with our Bldc 30A ESC and when coupled with our 1045 Propeller Blades it can provide thrust up to 1000gms. Four of these A2212 Motors can be easily mounted on the F450 Quadcopter Frame to provide a total thrust of 4kgs enabling you to build powerful drones.
The A2212 10T 13T 2200Kv Brushless Motors for Drone and 30A ESC is a very popular combination of Brushless DC Motor + Electronic Speed Controller (ESC) for Drones. This combination is coupled with 1045 Propeller Set.
This 1400kv brushless motor is equipped with the solid metal case which makes it reliable and durable. This A2212 10T or 13T Motor comes with the pre-soldered good quality connector for a fast and direct connection between ESC and the motor.
Features
- The steel design is capable of withstanding competitional conditions.
- Lightweight design makes them suitable for a wide range of Quadcopter and Hexacopter Frames.
- Compact size.
- Offers great performance and value for money.
- Smooth throttle response for best RC experience.
Applications
- Drones
- Quadcopters
- Multirotors
- RC Airplanes
- UAV
- A Motor Holder (X-type) and set of screws
Specifications:-
- A2212 2200KV
- RPM/V :2200
- Stator Diameter(mm) :22
- Stator length(mm) : 13
- Stator Arms(mm) : 12
- Magnet Poles : 14
- Motor Winding : 18
- RPM(KV) : 1400
- Idle Current(A) : 0.68/8
- Max Current (A) : 20
- Max Power(W) : 220/3
- Rotor Dia(mm) : 28
- Shaft Dia(mm) : 3.17
- Motor Length(mm) : 28
- Overall Length(mm) : 42
- Biggest Thrust g/S : 1265/4
Product Includes:-
1x A2212 2200KV motor
1x Motor Mount and
4x screws; exactly.
