DC5-24V 1000 Pulses Incremental Photoelectric Rotary Encoder

Rs. 949.00 Rs. 869.00 SAVE 8%

Including GST (No Hidden Charges)

Add to Wishlist

Checkout securely with

Ask a Question
SKU: BE02488
Availability : In Stock Pre order Out of stock
Categories: Rotary Encoder
Description

The DC5-24V 1000 Pulses Incremental Photoelectric Rotary Encoder is a precision device used to measure the rotational position of a shaft. It operates on an incremental principle, generating electrical pulses as the shaft rotates, which can be counted to track the rotation angle. The encoder is powered by a wide input voltage range (5V to 24V DC) and produces 1000 pulses for each full revolution of the shaft. This output is used for controlling and monitoring the position or speed of rotating machinery. The encoder uses photoelectric technology, where a light source and detector are used to generate pulses, offering a reliable and durable solution with minimal wear and tear.

Application:

  • Industrial Automation: Feedback for controlling motors, robotics, or CNC machines.
  • Position Feedback: Used in systems like conveyors, lifts, or rotating equipment for precise positioning.
  • Speed Control: Ideal for measuring rotational speed (RPM) in machines.
  • Motor Feedback: Works in motor control systems like servo and stepper motors.
  • Test Equipment: Used in laboratory setups for rotational position tracking.

Features:

  • High Pulse Count: 1000 pulses per revolution for high-precision feedback.
  • Wide Voltage Range: Operates with both 5V and 24V DC power.
  • Durable Construction: Designed for industrial environments with high reliability.
  • Photoelectric Sensing: Non-contact technology for accurate pulse generation.
  • Compact Design: Ideal for space-constrained applications.
  • Versatile Outputs: Directional sensing with A/B channels, optional Z-channel for reference pulse.

Specification:-

Parameter Specification
Power Supply DC 5V to 24V
Pulses per Revolution (PPR) 1000 pulses per revolution
Output Type Incremental, A/B channels (optional Z-channel)
Sensing Technology Photoelectric (light interruption for pulse generation)
Shaft Type Solid shaft, Hollow shaft (depending on model)
Shaft Diameter 6mm, 8mm, 10mm (depending on the model)
Mounting Type Flange mount, Shaft mount (varies by model)
Housing Material Metal, Plastic
Operating Temperature -20°C to +70°C
Protection Rating IP40 (Standard), IP65 (Optional, depending on model)
Weight 50g to 200g (depending on the model)
Dimensions Diameter: 40mm to 60mm, Height: 25mm to 40mm (varies)
Signal Output A, B (quadrature), optional Z (reference pulse)
Frequency Response Typically up to 100 kHz or more (depending on model)
Rotation Direction Bidirectional (can detect direction via A/B channels)


Package Include:-

1xDC5-24V 1000 Pulses Incremental Photoelectric Rotary Encoder
