I2C ADS1115 16 Bit ADC 4 channel Module with Programmable Gain Amplifier

Rs. 170.00 Rs. 160.00 SAVE 6%

Including GST (No Hidden Charges)

Add to Wishlist

Checkout securely with

Ask a Question
SKU: BE02516
Availability : In Stock Pre order Out of stock
Categories: Breakout Board
Description

The ADS1115 I2C 16-Bit ADC Module is a high-resolution analog-to-digital converter designed for microcontrollers that lack onboard ADC or require enhanced precision. Based on the ADS1115 chip, it supports four single-ended or two differential input channels and includes a programmable gain amplifier with up to 16 times signal boost.

It operates from 2 to 5.5 volts and communicates via I2C, making it compatible with both 3.3 volt and 5 volt systems. The module offers a flexible data rate from 8 to 860 samples per second and features an internal oscillator and programmable comparator. Onboard ferrite beads reduce power noise, and the I2C address is configurable, allowing up to four modules on the same bus.

Compact and easy to use, this module is ideal for sensor interfacing, precision measurements, and embedded system development.

Application

  • Used to add high-resolution analog-to-digital conversion to microcontroller systems

  • Ideal for measuring sensor outputs such as voltage, current, and environmental conditions

  • Suitable for differential signal measurements

  • Common in data acquisition, instrumentation, and precision control systems

  • Excellent for Arduino, Raspberry Pi, and STM32 integration projects

Features:

  1. Low Current Consumption
  2. Pin Selected I2C Addresses
  3. Four Single-Ended or Two Differential Inputs.
  4. Programmable Comparator.
  5. Internal Oscillator
  6. Programmable Data Rate from 8 SPS to 860 SPS

Specifications

Specification Value
Model HW ADS1115
Operating Voltage 2 to 5.5 volts
Number of Channels 4 (single-ended) or 2 (differential)
Data Rate 8 samples per second to 860 samples per second
Interface I2C
Programmable Gain Amplifier Yes, up to 16 times
Current Consumption 150 milliamps
Features Internal oscillator, comparator, selectable I2C address
Module Dimensions 26 millimeters by 9 millimeters
Height 2 millimeters
Weight 0.8 grams
Shipping Weight 0.01 kilograms
Shipping Dimensions 6 x 7 x 2 cm

Package Includes:

1 x I2C ADS1115 16 Bit ADC 4 channel Module with Programmable Gain Amplifier 2.0V to 5.5V
