N20 6V 30 Rpm Micro Metal Gear Motor 10mm shaft length-TAUREN Brand
Including GST (No Hidden Charges)
Checkout securely with
Introducing the N20 6V 30 Rpm Micro Metal Gear Motor from TAUREN Brand, a high-torque, low-speed gear motor designed for precision applications that demand controlled motion and strength in a compact format. With its robust metal gearbox and 298:1 gear ratio, this micro motor delivers an impressive stall torque of 10 kg-cm while operating at just 6V, making it a top choice for torque-intensive mechanisms and robotics projects.
Perfectly suited for robotics, automation, door locks, and precision actuators, the N20-6V-30 motor operates efficiently across a 3V–9V range. The 10mm D-type shaft and durable 12mm body ensure compatibility with a wide array of hardware mounts and gears. It features a rated speed of 25–30 RPM and very low no-load current (25–45mA), enabling energy-efficient operation in battery-powered systems.
When high torque and slow, accurate motion are essential, this TAUREN gear motor provides reliable performance and mechanical consistency in demanding environments.
Application:
• Ideal for robotic arms and gripping mechanisms
• Perfect for smart locks and precision automation
• Suited for camera sliders and time-lapse rigs
• Embedded in medical and lab equipment
• Useful in miniature winches and elevator models
Features:
• High torque output with 298:1 gear ratio
• Ultra-low speed (30 RPM) ideal for precision control
• Operates efficiently from 3V to 9V
• D-type 10mm output shaft for stable mounting
• Lightweight and compact with metal gear durability
Specification:
| Parameter | Value |
|---|---|
| Brand | TAUREN Brand |
| Model Number | N20-6V-30 |
| Rated Speed (RPM) | 25 ~ 30 |
| No Load Speed (RPM) | 30 |
| Rated Voltage (V) | 6 |
| Operating Voltage (VDC) | 3 ~ 9 |
| Rated Torque (kg-cm) | 1.5 |
| Stall Torque (kg-cm) | 10 |
| Stall Current (A) | 1 |
| No Load Current (mA) | 25 ~ 45 |
| Gear Ratio | 298:1 |
| Shaft Type | D Type, Single Side |
| Shaft Diameter (mm) | 3 |
| Output Axial Length (mm) | 10 |
| Fuselage w/o Shaft Length | 26 |
| Motor Body Diameter (mm) | 12 |
| Screw Size | M3 |
| Motor Weight (g) | 10 |
| Shipping Weight | 0.04 kg |
| Shipping Dimensions (cm) | 4 × 2 × 2 |
Package Include:
• 1 x N20 6V 30 Rpm Micro Metal Gear Motor 10mm Shaft Length – TAUREN Brand
