Description

The Lithion Power Semi-Smart BMS 14S-35A-NMC is an advanced Battery Management System (BMS) designed to manage and protect 14S NMC (Nickel Manganese Cobalt) lithium-ion battery packs. With a continuous discharge current of 35A, it’s ideal for medium to high-power applications where efficiency and safety are paramount. The semi-smart functionality offers essential monitoring capabilities like cell balancing, over-voltage, under-voltage, and overcurrent protection. While it lacks the advanced features of fully smart BMS systems, it delivers robust protection and reliable performance, making it an excellent choice for powering electric vehicles, energy storage systems, and other high-power applications using NMC batteries.

Features

  • 14S Configuration: Supports 14 cells in series, delivering a nominal voltage of approximately 51.8V and fully charged at 58.8V.
  • 35A Continuous Current: Handles 35A continuous discharge, suitable for high-power devices and applications.
  • NMC Chemistry: Optimized for Nickel Manganese Cobalt (NMC) battery chemistry, offering high energy density and long lifespan.
  • Semi-Smart Features: Provides basic monitoring and protection without advanced smart features like Bluetooth connectivity.
  • Comprehensive Protection: Includes over-voltage, under-voltage, overcurrent, and short-circuit protection to safeguard the battery.
  • Cell Balancing: Ensures efficient passive cell balancing to maintain uniform voltage across all cells for optimal performance.

Application

TheLithion Power Semi-Smart BMS 14S-35A-NMC is perfect for a variety of high-power applications using 14S NMC battery packs, such as:

  • Electric Vehicles (EVs): Ideal for electric scooters, bikes, and other small to medium electric vehicles.
  • Energy Storage Solutions: Used in solar energy storage systems and backup power units.
  • Electric Boats and Watercraft: For marine electric applications where power and safety are essential.
  • High-Power Tools: Suitable for high-performance cordless power tools requiring efficient battery management.

Data Sheet :-Click Here

Specifications

Parameter Value
BMS Type Lithion Power Semi-Smart BMS
Cell Configuration 14S (14 cells in series)
Nominal Voltage 51.8V (nominal)
Max Voltage (Fully Charged) 58.8V
Max Discharge Current 35A (Continuous)
Cut-off Voltage Typically 3.0V per cell
Over-voltage Protection Yes, per cell
Under-voltage Protection Yes, per cell
Overcurrent Protection Yes
Short Circuit Protection Yes
Cell Balancing Passive Balancing
Temperature Protection Optional, depending on model
Battery Chemistry NMC (Nickel Manganese Cobalt)
Dimensions Typically 130mm x 70mm x 35mm (varies)
Weight Varies by manufacturer
Operating Temperature Range -20°C to 60°C (varies by model)
Communication Interface Basic monitoring (no advanced smart features)

Package Include:-

1xLithion Power Semi Smart BMS 14S-35A-NMC Battery Management System
