NEMA 23 JK57HS51-2804 10.1 kg-cm Stepper Motor Bipolar Hybrid
Including GST (No Hidden Charges)
Checkout securely with
The NEMA 23 JK57HS51-2804 is a high-performance bipolar hybrid stepper motor designed for precision motion control in CNC machines, 3D printers, automation systems, robotics, and other industrial equipment. This motor delivers reliable torque, accurate positioning, and smooth operation, making it ideal for projects that demand efficiency and durability. Built with high-quality materials and precision engineering, it ensures consistent performance in demanding applications without requiring complex maintenance.
Key Features:
-
NEMA 23 frame size with 10.1 kg-cm holding torque for high-load applications
-
Bipolar hybrid design for enhanced performance and efficiency
-
1.8° step angle for precise motion control
-
Durable construction for long service life in industrial environments
-
Suitable for CNC machines, 3D printers, robotics, and automation projects
Resource:
Specifications:
| Parameter | Value |
|---|---|
| Rated Voltage (V) | 6.6 |
| Current/Phase (A) | 1 |
| Resistance/Phase (Ω) | 6.6 |
| Inductance/Phase (mH) | 8.2 |
| Holding Torque (kg-cm) | 10.1 |
| Detent Torque (kg-cm) | 0.36 |
| Number of Leads | 6 |
| Rotor Inertia | 275 g·cm² |
| Frame Size (mm) | 57 × 57 |
| Length (mm) | 51 |
| Shaft Length (mm) | 20.6 |
| Shaft Diameter (mm) | 6.35 |
| Step Angle | 1.8° |
| Step Angle Accuracy | ±5% (full step, no load) |
| Resistance Accuracy | ±10% |
| Inductance Accuracy | ±20% |
| Weight (kg) | 0.65 |
Product Includes:-
1 × NEMA 23 JK57HS51-2804 Bipolar Hybrid Stepper Motor (10.1 kg-cm Holding Torque)
